NW-LKD12A Apertured Series Operation Shadowless Lamp
Material technology
The lampshade shell is made of high-quality aluminum alloy. The surface adopts the high-voltage electrostatic spraying process, and the imported environmentally friendly antibacterial plastic powder that used to ensures that the product meets the requirements of surgical hygiene. Also, this product has matte surface and no glint.
Bulb
It uses OSRAM high-quality LED light-emitting chips, the chip life is up to more than 50,000 hours, 40 times longer than the life of traditional halogen lamps.
Color rendering index
The color rendering index is as high as 85, which truly reflects the color of human tissues. It is suitable for various surgical scenes and greatly reduces the visual fatigue of medical staff due to long-term operations.
Temperature rise (surgical field)
Temperature rise (surgical field)（℃）: ≤2, this can avoid tissue drying due to high temperature and rapid blood clots at the wound, which will affect the operation.
Lamp holder structure
The lamp holder is equipped with multiple light sources and reflectors to focus on the working plane, which can effectively eliminate the shadows on the surgical site formed by the surgeon's head, shoulders and arms.
Lamp arm structure
The lamp holder is equipped with multiple light sources and reflectors to focus on the working plane, which can effectively eliminate the shadows on the surgical site formed by the surgeon's head, shoulders and arms.
Technical parameters
| Diameter of lighthead (mm) | 900 |
| Brightness control range | 40-100% |
| Color Rendering Index (CRI) | ≥85 |
| Temperature rise (Surgeon head)(℃) | ≤2 |
| Temperature rise (surgical field)(℃) | ≤2 |
| Total Irradiance Ee (W/m2) | ≤2000 |
| Radiant Power Ee/Ec (mW/m2lux) | ≤6 |
| Effective Focusing Depth (cm) | 40-45 |
| Lighting Spot Size (cm) | 20±1 |
| L1+L2 depth of illumination (cm) | ≥30 |
| Bulb Type | LED |
| Bulb Brand | OSRAM |
| Bulb Quantity | 48 |
| Bulb Power (w) | 1 |
| Average Bulb Life (hours) | ≥50000 |
Technical configuration
| Rotating arm parts | 1 set |
| Balance arm | 1 set |
| Main light | 1 set |
| Auxiliary light | 1 set |
| handle | 1 pc |
| fuse | 2 pcs |
